BFB1012VH-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Centrifugal Ball Bearing 12V 7V to 13.2V 37.97CFM 60dB
PDF
/
Buying Options
Total Price: USD $27.14
Unit Price: USD $27.139912
≥1 USD $27.139912
≥10 USD $25.603694
≥100 USD $24.154432
≥500 USD $22.787203
≥1000 USD $21.497354
Inventory: 1133
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 33mm
Length 97.2mm
Technical
Static Pressure 1.952 in H2O (486.2 Pa)
Voltage Range 7V~13.2VDC
Noise 60.0 dB(A)
Air Flow 38.0 CFM (1.06m3/min)
Fan Type Blower
Bearing Type Ball
RPM 4500 RPM
Rated Current 1.5A
Operating Supply Voltage 12V
Approval Agency CE, CSA, UR, VDE
Depth 94.4mm
Current Rating (Amps) 1.50A
Power Rating 18W
Additional Feature APPROVALS: UL; VDE
Voltage - Rated 12VDC
Termination 2 Wire Leads
Part Status Active
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Series BFB
Published 2015
Physical
Weight 180g
Housing Material Plastic
Supply Chain
Factory Lead Time 15 Weeks
