BFB1012M-F00

Delta Electronics
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN BLOWER 97.2X33MM 12VDC WIRE
PDF
/
Inventory: 7070
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 33.00mm
Length 97.2mm
Height 94.4mm

Technical

Static Pressure 0.748 in H2O (186.3 Pa)
Voltage Range 4V~13.8VDC
Noise 49.0 dB(A)
Air Flow 22.6 CFM (0.633m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3200 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 570mA
Max Power Dissipation 6.84W
Current Rating (Amps) 0.570A
Voltage - Rated 12VDC
Power (Watts) 6.84W
Min Operating Temperature 14°C
Max Operating Temperature 140°C
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Locked Rotor Protection, Speed Sensor (Tach)
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Series BFB
Published 2003
Operating Temperature 14~140°F -10°C~60°C

Physical

Material - Blade Plastic
Material - Frame Plastic
Weight 0.353lb 160.12g
Mount Wire
