BFB1012M-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 97.2X33MM 12VDC WIRE
PDF
/
Inventory: 5333
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 33mm
Length 97.2mm
Height 94.4mm
Technical
Static Pressure 0.893 in H2O (222.4 Pa)
Voltage Range 4V~13.2VDC
Noise 52.5 dB(A)
Air Flow 22.6 CFM (0.633m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3200 RPM
Operating Supply Voltage 12V
Approval Agency CE, CSA, UL, VDE
Current Rating 550mA
Reach Compliance Code unknown
Max Power Dissipation 6.6W
Current Rating (Amps) 0.550A
Power Rating 6.6W
Additional Feature APPROVALS: UL; VDE
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Series BFB
Published 2005
Physical
Material - Frame Plastic
Weight 0.366lb 166.01g
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
