BFB1012L-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 96.6X32.9MM 12VDC
PDF
/
Buying Options
Total Price: USD $22.89
Unit Price: USD $22.8888
≥1 USD $22.8888
≥10 USD $21.296
≥100 USD $19.166048
≥500 USD $17.568883
≥1000 USD $16.504162
≥3000 USD $14.374545
Inventory: 348
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 33mm
Length 97.2mm
Height 94.4mm
Technical
Static Pressure 0.585 in H2O (145.7 Pa)
Voltage Range 4V~13.2VDC
Noise 49.5 dB(A)
Air Flow 23.2 CFM (0.650m3/min)
Fan Type Blower
Bearing Type Ball
RPM 2700 RPM
Operating Supply Voltage 12V
Approval Agency CE, CSA, UL, VDE
Current Rating 370mA
Reach Compliance Code unknown
Max Power Dissipation 4.44W
Current Rating (Amps) 0.370A
Power Rating 4.44W
Additional Feature APPROVALS: UL; VDE
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Series BFB
Published 2007
Physical
Material - Frame Plastic
Weight 0.397lb 180.08g
Supply Chain
Factory Lead Time 19 Weeks
