BFB1012L
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Centrifugal Ball Bearing 12V 4V to 13.2V 23.17CFM 49.5dB
PDF
/
Inventory: 2538
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 33mm
Length 97.2mm
Height 94.4mm
Technical
Static Pressure 0.500 in H2O (124.5 Pa)
Voltage Range 4V~13.8VDC
Noise 45.0 dB(A)
Air Flow 19.1 CFM (0.535m3/min)
Fan Type Blower
Bearing Type Ball
RPM 2700 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 320mA
Reach Compliance Code unknown
Depth 94.4mm
Max Power Dissipation 3.84W
Current Rating (Amps) 0.320A
Power Rating 4.44W
Additional Feature APPROVALS: UL; VDE
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Series BFB
Published 2003
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.353lb 160.12g
Mount Flanges
