BFB1012HH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Centrifugal Ball Bearing 12V 7V to 13.2V 34.28CFM 57dB
PDF
/
Inventory: 4693
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 94.4mm
Technical
Static Pressure 1.300 in H2O (323.6 Pa)
Voltage Range 4V~13.2VDC
Noise 55.0 dB(A)
Air Flow 28.3 CFM (0.792m3/min)
Fan Type Blower
Bearing Type Ball
RPM 4000 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 1.1A
Reach Compliance Code unknown
Depth 94.4mm
Max Power Dissipation 13.2W
Power Rating 15W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Series BFB
Published 2011
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.353lb 160.12g
Mount Flanges
