BFB1012HD-04D4L

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 100X98X20MM 12V DC BLOWER W/PWM
PDF
/
Buying Options
Total Price: USD $31.39
Unit Price: USD $31.39332
≥1 USD $31.39332
≥10 USD $29.616335
≥100 USD $27.939941
≥500 USD $26.358445
≥1000 USD $24.866453
Inventory: 1131
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Static Pressure 1.620 in H2O (403.5 Pa)
Voltage Range 9V~16VDC
Noise 50.5 dB(A)
Air Flow 18.3 CFM (0.512m3/min)
Fan Type Blower
Bearing Type Ball
RPM 4000 RPM
Lifetime @ Temp 50000 Hrs @ 40°C
Ingress Protection IP55 - Dust Protected, Water Resistant
Current Rating (Amps) 580mA
Voltage - Rated 12VDC
Power (Watts) 6.96W
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection, PWM Control
Size / Dimension Rectangular/Rounded - 100mm Lx80mm H
Series BFB
Operating Temperature -40~185°F -40°C~85°C

Physical

Material - Frame Plastic
Weight 0.276lb 125.19g

Supply Chain

Factory Lead Time 19 Weeks
