BFB1012H-R00
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 97.2X33MM 12VDC WIRE
PDF
/
Inventory: 5739
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Wire
Weight 0.353lb 160.12g
Material - Frame Plastic
Material - Blade Plastic
Technical
Published 2003
Series BFB
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Feature Locked Rotor Sensor
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Power (Watts) 9.6W
Voltage - Rated 12VDC
Current Rating (Amps) 0.800A
Max Power Dissipation 9.6W
Current Rating 800mA
Approval Agency CE, CSA, UL, VDE
RPM 3600 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 25.4 CFM (0.711m3/min)
Noise 52.0 dB(A)
Voltage Range 4V~13.8VDC
Static Pressure 1.000 in H2O (249.1 Pa)
Dimensions
Height 94.4mm
Length 97.2mm
Width 33.00mm
Compliance
RoHS Status RoHS Compliant
