BFB1012EH-C18J
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
97X94X33MM 12VDC BLOWER W/SPEED
PDF
/
Buying Options
Total Price: USD $20.15
Unit Price: USD $20.145165
≥1 USD $20.145165
≥10 USD $19.004865
≥100 USD $17.929129
≥500 USD $16.91427
≥1000 USD $15.956857
Inventory: 1167
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 32.90mm
Technical
Static Pressure 3.694 in H2O (920.1 Pa)
Voltage Range 10.8V~14VDC
Noise 62.0 dB(A)
Air Flow 45.5 CFM (1.27m3/min)
Fan Type Blower
Bearing Type Ball
RPM 5800 RPM
Lifetime @ Temp 90000 Hrs @ 35°C
Current Rating (Amps) 1.97A
Voltage - Rated 12VDC
Power (Watts) 23.64W
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Size / Dimension Rectangular/Rounded - 96.6mm Lx94.3mm H
Series BFB - High-Performance
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Supply Chain
Factory Lead Time 19 Weeks
