BFB0724L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 75.7X30MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $17.15
Unit Price: USD $17.1512
≥1 USD $17.1512
≥10 USD $16.36888
≥100 USD $14.810048
≥500 USD $13.640836
≥1000 USD $12.237817
≥3000 USD $11.302412
Inventory: 198
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 75.7mm
Technical
Static Pressure 0.157 in H2O (39.1 Pa)
Voltage Range 14V~27.6VDC
Noise 26.0 dB(A)
Air Flow 7.0 CFM (0.196m3/min)
Fan Type Blower
Bearing Type Ball
RPM 1900 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Operating Supply Voltage 24V
Approval Agency CE, CSA, UL, VDE
Current Rating 50mA
Reach Compliance Code unknown
Max Power Dissipation 1.2W
Current Rating (Amps) 0.050A
Power Rating 1.2W
Voltage - Rated 24VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square/Rounded - 75.7mm Lx75.7mm H
Series BFB
Published 2009
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.209lb 94.8g
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
Alternative Model
