BFB0712M-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
70X70X25MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Buying Options
Total Price: USD $17.97
Unit Price: USD $17.9696
≥1 USD $17.9696
≥10 USD $17.15296
≥100 USD $15.519328
≥500 USD $14.294192
≥1000 USD $12.823879
≥3000 USD $11.843718
Inventory: 200
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.198lb 89.81g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2013
Series BFB
Size / Dimension Square/Rounded - 75.7mm Lx75.7mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Max Operating Temperature 158°C
Min Operating Temperature 14°C
Power (Watts) 1.92W
Voltage - Rated 12VDC
Power Rating 1.92W
Current Rating (Amps) 0.160A
Max Power Dissipation 1.92W
Current Rating 160mA
Approval Agency CE, CSA, UL, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 50000 Hrs @ 40°C
Life (Hours) 50000 hours
RPM 3400 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 11.3 CFM (0.316m3/min)
Noise 43.0 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.478 in H2O (119.1 Pa)
Dimensions
Height 75.7mm
Length 75.7mm
Width 25.00mm
Compliance
RoHS Status ROHS3 Compliant
