BFB0712H-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
70X70X25MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Buying Options
Total Price: USD $17.97
Unit Price: USD $17.9696
≥1 USD $17.9696
≥10 USD $17.15296
≥100 USD $15.519328
≥500 USD $14.294192
≥1000 USD $12.823879
Inventory: 383
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 25.00mm
Technical
Static Pressure 0.773 in H2O (192.5 Pa)
Voltage Range 7V~13.8VDC
Noise 48.0 dB(A)
Air Flow 13.8 CFM (0.386m3/min)
Fan Type Blower
Bearing Type Ball
RPM 4000 RPM
Lifetime @ Temp 50000 Hrs @ 40°C
Operating Supply Voltage 12V
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.270A
Power Rating 3.24W
Voltage - Rated 12VDC
Power (Watts) 3.24W
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection, Speed Sensor (Tach)
Size / Dimension Square/Rounded - 75.7mm Lx75.7mm H
Series BFB
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.199lb 90.26g
Housing Material Plastic
Supply Chain
Factory Lead Time 19 Weeks
Alternative Model
