BFB0512MA-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
50X50X10MM 12V DC BLOWER
PDF
/
Inventory: 7903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.05lb 22.68g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series BFB
Size / Dimension Square - 50mm Lx50mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 840mW
Voltage - Rated 12VDC
Power Rating 840mW
Current Rating (Amps) 0.070A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 30000 Hrs @ 40°C
RPM 4300 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 2.9 CFM (0.081m3/min)
Noise 28.0 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.383 in H2O (95.4 Pa)
Dimensions
Width 10.30mm
Compliance
RoHS Status ROHS3 Compliant
