BFB0512LA-CF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
50X50X10MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 7683
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Static Pressure 0.208 in H2O (51.8 Pa)
Voltage Range 7V~13.2VDC
Noise 22.5 dB(A)
Air Flow 2.2 CFM (0.061m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3500 RPM
Operating Supply Voltage 12V
Approval Agency CE, CSA, UL, VDE
Current Rating 50mA
Reach Compliance Code unknown
Max Power Dissipation 600mW
Current Rating (Amps) 0.050A
Power Rating 600mW
Voltage - Rated 12VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Locked Rotor Protection, Speed Sensor (Tach)
Size / Dimension Square - 50mm Lx50mm H
Series BFB
Published 2015
Physical
Material - Frame Plastic
Weight 0.049lb 22.23g
Supply Chain
Factory Lead Time 19 Weeks
