BFB0512LA-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
50X50X10MM 12V DC BLOWER
PDF
/
Inventory: 6970
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10.30mm
Technical
Static Pressure 0.208 in H2O (51.8 Pa)
Voltage Range 7V~13.2VDC
Noise 22.5 dB(A)
Air Flow 2.2 CFM (0.061m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3500 RPM
Lifetime @ Temp 30000 Hrs @ 40°C
Operating Supply Voltage 12V
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.050A
Power Rating 600mW
Voltage - Rated 12VDC
Power (Watts) 600mW
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 50mm Lx50mm H
Series BFB
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.05lb 22.68g
Housing Material Plastic
Supply Chain
Factory Lead Time 19 Weeks
