BFB0505HA-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
50X50X10MM 5V DC BLOWER
PDF
/
Buying Options
Total Price: USD $13.49
Unit Price: USD $13.4904
≥1 USD $13.4904
≥10 USD $12.8788
≥100 USD $11.652256
≥500 USD $10.732304
≥1000 USD $9.628344
≥3000 USD $8.892453
Inventory: 653
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.05lb 22.68g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series BFB
Size / Dimension Square - 50mm Lx50mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 900mW
Voltage - Rated 5VDC
Power Rating 900mW
Current Rating (Amps) 0.180A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 5V
Lifetime @ Temp 30000 Hrs @ 40°C
RPM 5100 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 3.5 CFM (0.098m3/min)
Noise 32.5 dB(A)
Voltage Range 3V~5.5VDC
Static Pressure 0.563 in H2O (140.2 Pa)
Dimensions
Width 10.30mm
Compliance
RoHS Status ROHS3 Compliant
