BFB04512VHD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
45X45X20MM 12V DC BLOWER
PDF
/
Buying Options
Total Price: USD $13.49
Unit Price: USD $13.4904
≥1 USD $13.4904
≥10 USD $12.8788
≥100 USD $11.652256
≥500 USD $10.732304
≥1000 USD $9.628344
≥3000 USD $8.892435
Inventory: 1471
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 20.00mm
Length 45mm
Technical
Static Pressure 0.557 in H2O (138.7 Pa)
Voltage Range 5V~13.8VDC
Noise 30.5 dB(A)
Air Flow 6.0 CFM (0.168m3/min)
Fan Type Blower
Bearing Type Ball
RPM 4500 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Operating Supply Voltage 12V
Approval Agency CE, CSA, UR, VDE
Depth 45mm
Current Rating (Amps) 0.160A
Power Rating 1.8W
Voltage - Rated 12VDC
Power (Watts) 1.92W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square/Rounded - 45mm Lx45mm H
Series BFB
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.038lb 17.24g
Housing Material Plastic
Supply Chain
Factory Lead Time 19 Weeks
