BFB04512MD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 12V 0.07A 0.84W 3300RPM 4.24CFM 21dBA Flange Mount
PDF
/
Inventory: 6503
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Thermal Support Device Type DC FAN
Static Pressure 0.269 in H2O (67.0 Pa)
Voltage Range 5V~13.8VDC
Noise 21.0 dB(A)
Air Flow 4.2 CFM (0.118m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3300 RPM
Life (Hours) 20000 hours
Lifetime @ Temp 20000 Hrs @ 70°C
Operating Supply Voltage 12V
Approval Agency CE, CSA, UL, VDE
Current Rating 70mA
Reach Compliance Code unknown
Depth 20mm
Max Power Dissipation 840mW
Current Rating (Amps) 0.070A
Power Rating 840mW
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square/Rounded - 45mm Lx45mm H
Series BFB
Published 2011
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.037lb 16.78g
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
