BFB04512MA-C

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 45X45X10MM 12V DC BLOWER
PDF
/
Inventory: 5176
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Housing Material Plastic
Weight 0.04lb 18.14g
Material - Frame Plastic
Material - Blade Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Series BFB
Size / Dimension Square - 45mm Lx45mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 720mW
Voltage - Rated 12VDC
Power Rating 720mW
Current Rating (Amps) 0.060A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 30000 Hrs @ 40°C
RPM 4500 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 2.6 CFM (0.073m3/min)
Noise 27.0 dB(A)
Voltage Range 5V~13.2VDC
Static Pressure 0.279 in H2O (69.5 Pa)

Dimensions

Width 10.30mm

Compliance

RoHS Status ROHS3 Compliant
