BFB04512LA-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
45X45X10MM 12V DC BLOWER
PDF
/
Inventory: 7767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.04lb 18.14g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series BFB
Size / Dimension Square - 45mm Lx45mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 600mW
Voltage - Rated 12VDC
Power Rating 600mW
Current Rating (Amps) 0.050A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 30000 Hrs @ 40°C
RPM 3900 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 2.0 CFM (0.056m3/min)
Noise 21.5 dB(A)
Voltage Range 5V~13.2VDC
Static Pressure 0.212 in H2O (52.8 Pa)
Dimensions
Width 10.30mm
Compliance
RoHS Status ROHS3 Compliant
