BFB04512HA-CF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
45X45X10MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Buying Options
Total Price: USD $12.5
Unit Price: USD $12.496
≥1 USD $12.496
Inventory: 34
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.04lb 18.14g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series BFB
Size / Dimension Square - 45mm Lx45mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Power (Watts) 960mW
Voltage - Rated 12VDC
Power Rating 960mW
Current Rating (Amps) 0.080A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 30000 Hrs @ 40°C
RPM 5150 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 3.0 CFM (0.084m3/min)
Noise 30.5 dB(A)
Voltage Range 5V~13.2VDC
Static Pressure 0.391 in H2O (97.4 Pa)
Dimensions
Width 10.30mm
Compliance
RoHS Status ROHS3 Compliant
