BFB0412ME
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 42X18.5MM 12VDC WIRE
PDF
/
Inventory: 8329
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 18.50mm
Length 40mm
Height 44.5mm
Technical
Static Pressure 0.233 in H2O (58.0 Pa)
Voltage Range 10V~13.8VDC
Noise 30.0 dB(A)
Air Flow 2.1 CFM (0.059m3/min)
Fan Type Blower
Bearing Type Ball
RPM 4500 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 50mA
Depth 40mm
Max Power Dissipation 600mW
Current Rating (Amps) 0.050A
Power Rating 600mW
Voltage - Rated 12VDC
Power (Watts) 600mW
Min Operating Temperature 14°C
Max Operating Temperature 158°C
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 42mm Lx44.5mm H
Series BFB
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.048lb 21.77g
Housing Material Plastic
Supply Chain
Factory Lead Time 19 Weeks
Alternative Model
