BFB0412HE image
Favorite
BFB0412HE image
Favorite
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN BLOWER 42X18.5MM 12VDC WIRE
PDF
/
Inventory: 9889
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 18.50mm
Height 44.5mm

Technical

Static Pressure 0.383 in H2O (95.4 Pa)
Voltage Range 10V~13.8VDC
Noise 35.5 dB(A)
Air Flow 2.5 CFM (0.070m3/min)
Fan Type Blower
Bearing Type Ball
RPM 5500 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 70mA
Max Power Dissipation 840mW
Current Rating (Amps) 0.070A
Voltage - Rated 12VDC
Power (Watts) 840mW
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 42mm Lx44.5mm H
Series BFB
Published 2011

Physical

Material - Blade Plastic
Material - Frame Plastic
Weight 0.048lb 21.77g
Mount Flanges
