BFB03505MA-C

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 35X35X10MM 5V DC BLOWER
PDF
/
Inventory: 3672
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 10.00mm

Technical

Static Pressure 0.236 in H2O (58.8 Pa)
Voltage Range 4.5V~5.5VDC
Noise 26.0 dB(A)
Air Flow 1.6 CFM (0.045m3/min)
Fan Type Blower
Bearing Type Ball
RPM 6500 RPM
Lifetime @ Temp 30000 Hrs @ 40°C
Current Rating (Amps) 0.120A
Voltage - Rated 5VDC
Power (Watts) 600mW
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 35mm Lx35mm H
Series BFB
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Blade Plastic
Material - Frame Plastic
Weight 0.025lb 11.34g

Supply Chain

Factory Lead Time 19 Weeks
