BFB0312MA-CF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
30X30X10MM 12V DC BLOWER W/SPEED
PDF
/
Buying Options
Total Price: USD $12.56
Unit Price: USD $12.5576
≥1 USD $12.5576
≥10 USD $11.98296
≥100 USD $10.8416
≥500 USD $9.985712
≥1000 USD $8.958576
≥3000 USD $8.27383
Inventory: 439
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series BFB
Size / Dimension Square - 30mm Lx30mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Power (Watts) 600mW
Voltage - Rated 12VDC
Current Rating (Amps) 0.050A
Lifetime @ Temp 30000 Hrs @ 40°C
RPM 6500 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 1.2 CFM (0.034m3/min)
Noise 26.0 dB(A)
Voltage Range 10.8V~13.2VDC
Static Pressure 0.206 in H2O (51.3 Pa)
Dimensions
Width 10.00mm
Compliance
RoHS Status ROHS3 Compliant
