BCB0812UHN-F00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
80X75X30MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 4954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series BCB
Size / Dimension Rectangular/Rounded - 80mm Lx75mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Termination 3 Wire Leads
Power (Watts) 27.6W
Voltage - Rated 12VDC
Power Rating 27.6W
Current Rating (Amps) 2.30A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 10800 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 30.2 CFM (0.846m3/min)
Noise 69.3 dB(A)
Voltage Range 6V~13.2VDC
Static Pressure 3.675 in H2O (915.4 Pa)
Dimensions
Width 30.00mm
Compliance
RoHS Status ROHS3 Compliant
