BCB0812UHN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
80X75X30MM 12V DC FAN
PDF
/
Inventory: 4315
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 30.00mm
Technical
Static Pressure 3.675 in H2O (915.4 Pa)
Voltage Range 6V~13.2VDC
Noise 69.3 dB(A)
Air Flow 30.2 CFM (0.846m3/min)
Fan Type Blower
Bearing Type Ball
RPM 10800 RPM
Lifetime @ Temp 50000 Hrs @ 40°C
Operating Supply Voltage 12V
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 2.30A
Power Rating 27.6W
Voltage - Rated 12VDC
Power (Watts) 27.6W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 80mm Lx75mm H
Series BCB
Published 2015
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic
Supply Chain
Factory Lead Time 17 Weeks
