AUB0924VH-A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X25.4MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $12.36
Unit Price: USD $12.3552
≥1 USD $12.3552
≥10 USD $11.7964
≥100 USD $10.67264
≥500 USD $9.830093
≥1000 USD $8.819008
≥3000 USD $8.144954
Inventory: 1159
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.218lb 98.88g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series AUB
Size / Dimension Square - 92mm Lx92mm H
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 24VDC
Power Rating 5.28W
Current Rating (Amps) 0.250A
Max Power Dissipation 6W
Reach Compliance Code unknown
Current Rating 250mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
Life (Hours) 50000 hours
RPM 3800 RPM
Bearing Type Superflo
Fan Type Tubeaxial
Air Flow 81.5 CFM (2.28m3/min)
Noise 46.0 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 0.345 in H2O (85.9 Pa)
Dimensions
Height 92mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
