ASB0305LA-CF00

Delta Electronics
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 30X30X10MM 5V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 9509
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height 30mm

Technical

Static Pressure 0.131 in H2O (32.6 Pa)
Voltage Range 4.5V~5.5VDC
Noise 21.0 dB(A)
Air Flow 3.2 CFM (0.090m3/min)
Fan Type Tubeaxial
Bearing Type Sleeve
RPM 8000 RPM
Lifetime @ Temp 20000 Hrs @ 40°C
Approval Agency CE, cURus, VDE
Current Rating 100mA
Reach Compliance Code unknown
Max Power Dissipation 500mW
Current Rating (Amps) 0.100A
Power Rating 500mW
Voltage - Rated 5VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Locked Rotor Protection, Speed Sensor (Tach)
Size / Dimension Square - 30mm Lx30mm H
Series ASB
Published 2010
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.016lb 7.26g
Package / Case Axial

Supply Chain

Factory Lead Time 17 Weeks
