AFC0948DE-TP20

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 92X38MM 48VDC WIRE
PDF
/
Inventory: 8640
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Package / Case Axial
Weight 0.573lb 259.91g
Material - Frame Plastic

Technical

Operating Temperature -40~149°F -40°C~65°C
Published 2007
Series AFC
Size / Dimension Square - 92mm Lx92mm H
Feature PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads
Voltage - Rated 48VDC
Power Rating 28.8W
Current Rating (Amps) 0.600A
Max Power Dissipation 28.8W
Current Rating 600mA
Approval Agency CE, TUV, UL
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 7500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 159.4 CFM (4.46m3/min)
Noise 67.0 dB(A)
Voltage Range 36V~75VDC
Static Pressure 1.528 in H2O (380.6 Pa)

Dimensions

Height 92mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
