AFB1712L-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 12V 0.56A 6.72W 2400RPM 160.77CFM 46dB Flange Mount
PDF
/
Inventory: 3273
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 25.40mm
Length 172mm
Height 172mm
Technical
Static Pressure 0.305 in H2O (75.9 Pa)
Voltage Range 6V~14VDC
Noise 46.0 dB(A)
Air Flow 160.8 CFM (4.50m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2400 RPM
Lifetime @ Temp 80000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.560A
Power Rating 6.72W
Voltage - Rated 12VDC
Power (Watts) 6.72W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Round - 172mm Dia
Series AFB
Published 2012
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Aluminum
Housing Material Plastic
