AFB1712H-A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 172X25.4MM 12VDC WIRE
PDF
/
Inventory: 9323
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.992lb 449.96g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2005
Series AFB
Size / Dimension Round - 172mm Dia
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power Rating 11.76W
Voltage - Rated DC 12V
Current Rating (Amps) 0.980A
Max Power Dissipation 11.8W
Reach Compliance Code unknown
Current Rating 980mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
Life (Hours) 80000 hours
RPM 3000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 202.5 CFM (5.67m3/min)
Noise 52.0 dB(A)
Voltage Range 6V~14VDC
Static Pressure 0.467 in H2O (116.3 Pa)
Dimensions
Height 172mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
