AFB1548L-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
172X150X25.4MM 48V DC FAN
PDF
/
Inventory: 3110
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 25.40mm
Length 172mm
Height 150mm
Technical
Static Pressure 0.305 in H2O (75.9 Pa)
Voltage Range 24V~60VDC
Noise 46.0 dB(A)
Air Flow 160.8 CFM (4.50m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2400 RPM
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.170A
Power Rating 8.16W
Voltage - Rated 48VDC
Power (Watts) 8.16W
Termination 2 Wire Leads
Part Status Active
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Series AFB
Physical
Material - Blade Plastic
Material - Frame Aluminum
Housing Material Plastic
Supply Chain
Factory Lead Time 20 Weeks
