AFB1548H-AR00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
172X150X25.4MM 48V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Housing Material Plastic
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series AFB
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Power (Watts) 12.96W
Voltage - Rated 48VDC
Power Rating 12.96W
Current Rating (Amps) 0.270A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
RPM 3000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 204.6 CFM (5.73m3/min)
Noise 52.5 dB(A)
Voltage Range 24V~60VDC
Static Pressure 0.407 in H2O (101.4 Pa)
Dimensions
Height 150mm
Length 172mm
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
