AFB1524L-A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 24V 0.31A 7.44W 2400RPM 160.77CFM 46dB Flange Mount
PDF
/
Buying Options
Total Price: USD $68.61
Unit Price: USD $68.6136
≥1 USD $68.6136
≥10 USD $62.0774
≥100 USD $53.909293
≥500 USD $50.64209
≥1000 USD $44.107554
Inventory: 135
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 150mm
Technical
Static Pressure 0.305 in H2O (75.9 Pa)
Voltage Range 12V~30VDC
Noise 46.0 dB(A)
Air Flow 160.8 CFM (4.50m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2400 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 310mA
Depth 150mm
Max Power Dissipation 7.44W
Current Rating (Amps) 0.310A
Voltage - Rated DC 24V
Power Rating 7.44W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Series AFB
Published 2007
Physical
Material - Blade Plastic
Material - Frame Aluminum
Weight 0.948lb 430.01g
Housing Material Aluminium
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
