AFB1524H-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
172X150X25.4MM 24V DC FAN
PDF
/
Inventory: 8740
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 25.40mm
Length 172mm
Height 150mm
Technical
Static Pressure 0.467 in H2O (116.3 Pa)
Voltage Range 12V~30VDC
Noise 52.0 dB(A)
Air Flow 202.5 CFM (5.67m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3000 RPM
Lifetime @ Temp 80000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.500A
Power Rating 12W
Voltage - Rated 24VDC
Power (Watts) 12W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Series AFB
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Aluminum
Housing Material Plastic
