AFB1524EH-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 24V 1.6A 38.4W 4300RPM 290.64CFM 61.5dB Flange Mount
PDF
/
Inventory: 8163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2014
Series AFB
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 38.4W
Voltage - Rated 24VDC
Power Rating 38.4W
Current Rating (Amps) 1.60A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
RPM 4300 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 290.6 CFM (8.14m3/min)
Noise 61.5 dB(A)
Voltage Range 15.8V~27.6VDC
Static Pressure 0.821 in H2O (204.5 Pa)
Dimensions
Height 150mm
Length 172mm
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
