AFB1512M-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
172X150X25.4MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 9833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Aluminum
Material - Blade Plastic
Technical
Series AFB
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Feature Speed Sensor (Tach)
Part Status Active
Termination 3 Wire Leads
Power (Watts) 9.12W
Voltage - Rated 12VDC
Power Rating 9.12W
Current Rating (Amps) 0.760A
Approval Agency CE, CSA, UR, VDE
RPM 2700 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 181.3 CFM (5.08m3/min)
Noise 49.0 dB(A)
Voltage Range 6V~14VDC
Static Pressure 0.382 in H2O (95.1 Pa)
Dimensions
Height 150mm
Length 172mm
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
