AFB1512H-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
172X150X25.4MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 8079
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 25.40mm
Length 172mm
Height 150mm
Technical
Static Pressure 0.467 in H2O (116.3 Pa)
Voltage Range 6V~14VDC
Noise 52.0 dB(A)
Air Flow 202.5 CFM (5.67m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3000 RPM
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.980A
Power Rating 11.76W
Voltage - Rated 12VDC
Power (Watts) 11.76W
Termination 3 Wire Leads
Part Status Active
Feature Speed Sensor (Tach)
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Series AFB
Published 2014
Physical
Material - Blade Plastic
Material - Frame Aluminum
Housing Material Plastic
