AFB1248HE-T500
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X38MM 48VDC WIRE
PDF
/
Buying Options
Total Price: USD $33.69
Unit Price: USD $33.6864
≥1 USD $33.6864
≥10 USD $31.33944
≥100 USD $28.205223
≥500 USD $25.85477
≥1000 USD $24.287754
≥3000 USD $21.153871
Inventory: 112
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.564lb 255.83g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2004
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 48VDC
Power Rating 5.76W
Current Rating (Amps) 0.120A
Max Power Dissipation 5.76W
Ingress Protection IP55 - Dust Protected, Water Resistant
Current Rating 120mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 2600 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 105.9 CFM (2.97m3/min)
Noise 41.0 dB(A)
Voltage Range 28V~56VDC
Static Pressure 0.300 in H2O (74.7 Pa)
Dimensions
Height 120mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings IP55, Water Resistant
