AFB1248GHE-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X120X38MM 48V DC FAN
PDF
/
Inventory: 7901
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 28.8W
Voltage - Rated 48VDC
Power Rating 28.8W
Current Rating (Amps) 0.600A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 5200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 241.0 CFM (6.75m3/min)
Noise 62.0 dB(A)
Voltage Range 24V~53VDC
Static Pressure 1.082 in H2O (269.5 Pa)
Dimensions
Height 120mm
Length 120mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
