AFB1224SHE-T500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 120X120X38MM
PDF
/
Inventory: 5823
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Static Pressure 0.571 in H2O (142.2 Pa)
Voltage Range 7V~27.6VDC
Noise 53.0 dB(A)
Air Flow 151.9 CFM (4.25m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3700 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Ingress Protection IP55 - Dust Protected, Water Resistant
Current Rating (Amps) 0.500A
Voltage - Rated 24VDC
Power (Watts) 12W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 120mm Lx120mm H
Series AFB
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Supply Chain
Factory Lead Time 18 Weeks
