AFB1224SHE-CF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X120X38MM 24V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 5741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Termination 3 Wire Leads
Power (Watts) 14.88W
Voltage - Rated 24VDC
Power Rating 14.88W
Current Rating (Amps) 0.620A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 4100 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 190.5 CFM (5.33m3/min)
Noise 55.5 dB(A)
Voltage Range 14V~28VDC
Static Pressure 0.694 in H2O (173.0 Pa)
Dimensions
Height 120mm
Length 120mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
