AFB1224LE-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X120X38MM 24V DC FAN
PDF
/
Inventory: 1854
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Length 120mm
Height 120mm
Technical
Static Pressure 0.166 in H2O (41.3 Pa)
Voltage Range 14V~27.6VDC
Noise 32.5 dB(A)
Air Flow 71.3 CFM (2.00m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2000 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.110A
Power Rating 2.64W
Voltage - Rated 24VDC
Power (Watts) 2.64W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 120mm Lx120mm H
Series AFB
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic
Supply Chain
Factory Lead Time 17 Weeks
