AFB1224HH
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X25.4MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $16.76
Unit Price: USD $16.7552
≥1 USD $16.7552
≥10 USD $15.99576
≥100 USD $14.47248
≥500 USD $13.329721
≥1000 USD $11.958707
≥3000 USD $11.044686
Inventory: 1436
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 38mm
Height 120mm
Technical
Thermal Support Device Type DC FAN
Static Pressure 0.304 in H2O (75.7 Pa)
Voltage Range 14V~27.6VDC
Noise 41.5 dB(A)
Air Flow 95.1 CFM (2.66m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2800 RPM
Speed 3500 rpm
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 180mA
Depth 120mm
Max Power Dissipation 4.32W
Current Rating (Amps) 0.180A
Power Rating 4.32W
Voltage - Rated 24VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 120mm Lx120mm H
Series AFB
Published 2004
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.436lb 197.77g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
