AFB1212VHE-CF00
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 12V 0.68A 8.16W 4000RPM 148.34CFM 51dB Flange Mount
PDF
/
Buying Options
Total Price: USD $29.79
Unit Price: USD $29.788
≥1 USD $29.788
≥10 USD $27.71296
Inventory: 68
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.706lb 320.24g
Material - Frame Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2010
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Voltage - Rated 12VDC
Power Rating 8.16W
Current Rating (Amps) 0.680A
Max Power Dissipation 8.16W
Depth 120mm
Current Rating 680mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 4000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 148.3 CFM (4.15m3/min)
Noise 51.0 dB(A)
Voltage Range 6V~12.8VDC
Static Pressure 0.602 in H2O (149.9 Pa)
Dimensions
Height 38mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
