AFB1212ME
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X120X38MM 12V WIRE
PDF
/
Buying Options
Total Price: USD $16.71
Unit Price: USD $16.71493
≥1 USD $16.71493
≥10 USD $15.768804
≥100 USD $14.876232
≥500 USD $14.03418
≥1000 USD $13.239793
Inventory: 1148
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.564lb 255.83g
Material - Frame Plastic
Technical
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 3.12W
Current Rating (Amps) 0.260A
Max Power Dissipation 3.12W
Depth 120mm
Current Rating 260mA
Approval Agency CE, CSA, UL, VDE
Speed 2500 rpm
RPM 2300 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 95.0 CFM (2.66m3/min)
Noise 38.0 dB(A)
Voltage Range 4V~13.2VDC
Static Pressure 0.236 in H2O (58.8 Pa)
Thermal Support Device Type DC FAN
Dimensions
Height 120mm
Width 38mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
