AFB1212L image
Favorite
AFB1212L image
Favorite
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Axial Ball Bearing 12V 7V to 13.8V 62.93CFM 32.5dB (120 X 120 X 25.4mm)
PDF
/
Buying Options
Total Price: USD $16.76
Unit Price: USD $16.7552
≥1 USD $16.7552
≥10 USD $15.99576
≥100 USD $14.47248
≥500 USD $13.329721
≥1000 USD $11.958707
≥3000 USD $11.044686
Inventory: 2466
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Package / Case Axial
Weight 0.436lb 197.77g
Material - Frame Plastic

Technical

Operating Temperature 14~140°F -10°C~60°C
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 1.68W
Current Rating (Amps) 0.140A
Max Power Dissipation 1.68W
Depth 120mm
Current Rating 140mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 1900 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 62.9 CFM (1.76m3/min)
Noise 32.5 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.154 in H2O (38.4 Pa)

Dimensions

Height 120mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
