AFB1212HHE-T8U5
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X38MM 12VDC WIRE
PDF
/
Inventory: 1362
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Axial
Weight 0.564lb 255.83g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2004
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Max Operating Temperature 140°C
Min Operating Temperature 14°C
Power (Watts) 5.52W
Voltage - Rated 12VDC
Current Rating (Amps) 0.460A
Max Power Dissipation 5.52W
Ingress Protection IP54 - Dust Protected, Water Resistant
Current Rating 460mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 2900 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 120.1 CFM (3.36m3/min)
Noise 44.0 dB(A)
Voltage Range 4V~13.2VDC
Static Pressure 0.354 in H2O (88.2 Pa)
Dimensions
Width 38.00mm
Compliance
RoHS Status RoHS Compliant
Ratings IP54, Water Resistant
Alternative Model
