AFB1212HE-R00
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X120X38MM 12V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Buying Options
Total Price: USD $18.79
Unit Price: USD $18.788
≥1 USD $18.788
≥10 USD $17.93704
≥100 USD $16.22867
≥500 USD $14.947407
≥1000 USD $13.409977
≥3000 USD $12.384988
Inventory: 96
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 120mm
Technical
Thermal Support Device Type DC FAN
Static Pressure 0.300 in H2O (74.7 Pa)
Voltage Range 4V~13.2VDC
Noise 41.0 dB(A)
Air Flow 105.9 CFM (2.97m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2600 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 320mA
Max Power Dissipation 3.84W
Current Rating (Amps) 0.320A
Power Rating 4.2W
Voltage - Rated 12VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Sensor
Size / Dimension Square - 120mm Lx120mm H
Series AFB
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.564lb 255.83g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
